| Design | Device Type | Smart Phone |
| OS | Android 6.0 (Marshmallow), upgradable to 7.0 (Nougat) |
| Dimension | 148.8 x 74.9 x 9.9 mm (5.86 x 2.95 x 0.39 in) |
| Weight | 184.8 g (6.53 oz) |
| Technology | 2G Network | GSM 850 / 900 / 1800 / 1900 |
| 3G Network | HSDPA 850 / 1900 / 2100 |
| 4G Network | LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 8(900), 12(700), 20(800), 29(700), 30(2300), 38(2600), 39(1900), 40(2300), 41(2500) |
| SIM | Nano-SIM - Samsung Pay (Visa, MasterCard certified) - IP68 certified - dust/water proof over 1.5 meter and 30 minutes - MIL-STD-810G certified - salt, dust, humidity, rain, vibration, solar radiation, transport and thermal shock resistant |
| Announced | June, 2016 |
| Status | June, 2016 |
| Display | Type | Super AMOLED capacitive touchscreen, 16M colors |
| Size | 5.1 inches (~64.3% screen-to-body ratio) |
| Multi-touch | Yes |
| Protection | Corning Gorilla Glass 4 - Always-on display - TouchWiz UI |
| Photography | Rear Camera | 12 MP, f/1.7, 26mm, phase detection autofocus, OIS, LED flash |
| Features | 1/2.5 sensor size, 1.4 µm pixel size, geo-tagging, simultaneous 4K video and 9MP image recording, touch focus, face/smile detection, Auto HDR, panorama |
| Video | 2160p@30fps, 1080p@60fps, 720p@240fps, Auto HDR, dual-video rec. |
| Front Camera | 5 MP, f/1.7, 22mm, dual video call, Auto HDR |
| Memory | Card slot | microSD, up to 256 GB (dedicated slot) |
| Internal | 32 GB, 4 GB RAM |
| Sound | Alert types | Vibration; MP3, WAV ringtones |
| Loudspeaker | Yes |
| 3.5mm jack | Yes - Active noise cancellation with dedicated mic |
| Connectivity | GPRS | Yes |
| EDGE | Yes |
| Speed | HSPA 42.2/5.76 Mbps, LTE-A (3CA) Cat9 450/50 Mbps |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot |
| Bluetooth | 4.2, A2DP, LE, aptX |
| NFC | Yes |
| USB | microUSB 2.0, USB Host |
| Battery | Capacity | Non-removable Li-Ion 4000 mAh battery |
| Stand-by | Up to 384 h (3G) |
| Talk time | Up to 32 h (3G) |
| Music play | Up to 110 h |
| Features | Chipset | Qualcomm MSM8996 Snapdragon 820 |
| CPU | Quad-core (2x2.15 GHz Kryo & 2x1.6 GHz Kryo) |
| GPU | Adreno 530 |
| Sensors | Fingerprint (front-mounted), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2 |
| Messaging | SMS(threaded view), MMS, Email, Push Mail, IM |
| Browser | HTML5 |
| Radio | Stereo FM radio, RDS |
| GPS | Yes, with A-GPS, GLONASS |
| Java | No |
| Colors | Camo Green, Titanium Gray, Sandy Gold |
| Others | - Fast battery charging (Quick Charge 2.0)
- Qi/PMA wireless charging (market dependent)
- ANT+ support
- S-Voice natural language commands and dictation
- OneDrive (115 GB cloud storage)
- MP4/DivX/XviD/WMV/H.264 player
- MP3/WAV/WMA/eAAC+/FLAC player
- Photo/video editor
- Document editor |
