| Design | Device Type | Smart Phone |
| OS | Android OS, v6.0.1 (Marshmallow), planned upgrade to v7.0 (Nougat) |
| Dimension | 153.5 x 73.9 x 7.9 mm (6.04 x 2.91 x 0.31 in) |
| Weight | 169 g (5.96 oz) |
| Technology | 2G Network | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 |
| 3G Network | HSDPA 850 / 900 / 1900 / 2100 |
| 4G Network | LTE |
| SIM | Single SIM (Nano-SIM) or Dual SIM (Nano-SIM, dual stand-by) - Stylus - Samsung Pay (Visa, MasterCard certified) |
| Announced | August, 2016 |
| Status | August, 2016 |
| Display | Type | Super AMOLED capacitive touchscreen, 16M colors |
| Size | 5.7 inches (~78.0% screen-to-body ratio) |
| Multi-touch | Yes |
| Protection | Corning Gorilla Glass 5 - Always-on display - TouchWiz UI |
| Photography | Rear Camera | 12 MP, f/1.7, 26mm, phase detection autofocus, OIS, LED flash |
| Features | 1/2.5 sensor size, 1.4 µm pixel size, geo-tagging, simultaneous 4K video and 9MP image recording, touch focus, face/smile detection, Auto HDR, panorama |
| Video | 2160p@30fps, 1080p@60fps, 720p@240fps, HDR, dual-video rec. |
| Front Camera | 5 MP, f/1.7, 22mm, dual video call, Auto HDR |
| Memory | Card slot | microSD, up to 256 GB (dedicated slot) - single-SIM model microSD, up to 256 GB (uses SIM 2 slot) - dual-SIM model |
| Internal | 64 GB, 4 GB RAM |
| Sound | Alert types | Vibration; MP3, WAV ringtones |
| Loudspeaker | Yes |
| 3.5mm jack | Yes |
| Connectivity | GPRS | Yes |
| EDGE | Yes |
| Speed | HSPA 42.2/5.76 Mbps, LTE Cat9 450/50 Mbps |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot |
| Bluetooth | v4.2, A2DP, EDR, LE |
| NFC | Yes |
| USB | v3.1, Type-C 1.0 reversible connector |
| Battery | Capacity | Non-removable Li-Po 3500 mAh battery |
| Features | Chipset | Exynos 8890 Octa |
| CPU | Quad-core 2.3 GHz Mongoose + quad-core 1.6 GHz Cortex-A53 |
| GPU | Mali-T880 MP12 |
| Sensors | Iris scanner, fingerprint, accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2 |
| Messaging | SMS(threaded view), MMS, Email, Push Mail, IM |
| Browser | HTML5 |
| Radio | To be confirmed |
| GPS | Yes, with A-GPS, GLONASS, BDS |
| Java | No |
| Colors | Black Sapphire, Gold Platinum, Silver Titan, White Pearl |
| Others | - Fast battery charging
- Qi wireless charging (market dependent)
- ANT+ support
- S-Voice natural language commands and dictation
- MP4/DivX/XviD/WMV/H.265 player
- MP3/WAV/WMA/eAAC+/FLAC player
- Photo/video editor
- Document editor |
